Different criteria for "broad" have been applied in different contexts and at different times. Its origin is in physics, acoustics, and radio systems engineering, where it had been used with a meaning similar to "wideband", or in the context of audio noise reduction systems, where it indicated a single-band rather than a multiple audio band system design of the compander. Later, with the advent of digital telecommunications, the term was mainly used for transmission over multiple channels. Whereas a passband signal is also modulated so that it occupies higher frequencies (compared to a baseband signal which is bound to the lowest end of the spectrum, see line coding), it is still occupying a single channel. The key difference is that what is typically considered a broadband signal in this sense is a signal that occupies multiple (non-masking, orthogonal) passbands, thus allowing for much higher throughput over a single medium but with additional complexity in the transmitter/receiver circuitry.
The term became popularized through the 1990s as a marketing term for Internet access that was faster than dialup access, the original Internet access technology, which was limited to a maximum bandwidth of 56 kbit/s. This meaning is only distantly related to its original technical meaning.
In telecommunications, a broadband signalling method is one that handles a wide band of frequencies. "Broadband" is a relative term, understood according to its context. The wider (or broader) the bandwidth of a channel, the greater the data-carrying capacity, given the same channel quality.
In radio, for example, a very narrow band will carry Morse code, a broader band will carry speech, and a still broader band will carry music without losing the high audio frequencies required for realistic sound reproduction. This broad band is often divided into channels or "frequency bins" using passband techniques to allow frequency-division multiplexing instead of sending a higher-quality signal.
In data communications, a 56k modem will transmit a data rate of 56 kilobits per second (kbit/s) over a 4-kilohertz-wide telephone line (narrowband or voiceband). In the late 1980s, the Broadband Integrated Services Digital Network (B-ISDN) used the term to refer to a broad range of bit rates, independent of physical modulation details. The various forms of digital subscriber line (DSL) services are broadband in the sense that digital information is sent over multiple channels. Each channel is at higher frequency than the baseband voice channel, so it can support plain old telephone service on a single pair of wires at the same time. However, when that same line is converted to a non-loaded twisted-pair wire (no telephone filters), it becomes hundreds of kilohertz wide (broadband) and can carry up to 100 megabits per second using very-high-bit-rate digital subscriber line (VDSL or VHDSL) techniques.
Many computer networks use a simple line code to transmit one type of signal using a medium's full bandwidth using its baseband (from zero through the highest frequency needed). Most versions of the popular Ethernet family are given names such as the original 1980s 10BASE5 to indicate this. Networks that use cable modems on standard cable television infrastructure are called broadband to indicate the wide range of frequencies that can include multiple data users as well as traditional television channels on the same cable. Broadband systems usually use a different radio frequency modulated by the data signal for each band.
The total bandwidth of the medium is larger than the bandwidth of any channel.
The DOCSIS standard became available to consumers in the late 1990s, to provide Internet access to cable television residential customers. Matters were further confused by the fact that the 10PASS-TS standard for Ethernet ratified in 2008 used DSL technology, and both cable and DSL modems often have Ethernet connectors on them.
A television antenna may be described as "broadband" because it is capable of receiving a wide range of channels, while a single-frequency or Lo-VHF antenna is "narrowband" since it receives only 1 to 5 channels. The U.S. federal standard FS-1037C defines "broadband" as a synonym for wideband. "Broadband" in analog video distribution is traditionally used to refer to systems such as cable television, where the individual channels are modulated on carriers at fixed frequencies. In this context, baseband is the term's antonym, referring to a single channel of analog video, typically in composite form with separate baseband audio. The act of demodulating converts broadband video to baseband video. Fiber optic allows the signal to be transmitted farther without being repeated. Cable companies use a hybrid system using fiber to transmit the signal to neighborhoods and then changes the signal from light to radio frequency to be transmitted over coaxial cable to homes. Doing so reduces the use of having multiple head ends. A head end gathers all the information from the local cable networks and movie channels and then feeds the information into the system.
However, "broadband video" in the context of streaming Internet video has come to mean video files that have bit-rates high enough to require broadband Internet access for viewing. "Broadband video" is also sometimes used to describe IPTV Video on demand.
Power lines have also been used for various types of data communication. Although some systems for remote control are based on narrowband signaling, modern high-speed systems use broadband signaling to achieve very high data rates. One example is the ITU-T G.hn standard, which provides a way to create a local area network up to 1 Gigabit/s (which is considered high-speed as of 2014) using existing home business and home wiring (including power lines, but also phone lines and coaxial cables).
In 2014, researchers at Korea Advanced Institute of Science and Technology made developments on the creation of ultra-shallow broadband optical instruments.
A range of more precise definitions of speed have been prescribed at times, including:
Broadband Internet service in the United States was effectively treated or managed as a public utility by net neutrality rules until being overturned by the FCC in December, 2017.
|Term||Regulator(s)||Min Download Mbps||Min Upload Mbps||Notes|
|Full fibre / FFTP/H||Ofcom||100||1|
|Ultra-fast / Gfast||EU, UK Government||100||1|
Bandwidth has historically been very unequally distributed worldwide, with increasing concentration in the digital age. Historically only 10 countries have hosted 70-75 % of the global telecommunication capacity (see pie-chart Figure on the right). In 2014, only three countries (China, US, Japan) host 50% of the globally installed telecommunication bandwidth potential. The U.S. lost its global leadership in terms of installed bandwidth in 2011, being replaced by China, which hosts more than twice as much national bandwidth potential in 2014 (29% versus 13% of the global total).
Broadband: Modulating the data signal onto an RF carrier and applying this RF signal to the carrier media
Broadband: relative term referring to a systemm which carries a wide frequency range.
Broadband networks employ frequency-division multiplexing to divide coaxial cable into separate channels, each of which serves as an individual local network.
